Yamaha TT-S303 Turntable

Yamaha TT-S303 Turntable - Yamaha

Yamaha heritage and a modern aesthetic designed to let you hear every detail in your vinyl collection. Pair with other Yamaha Hi-Fi components for exceptional sound and streaming capabilities.

• Belt-driven high inertia platter with DC motor to achieve stable rotation
• Built-in Phono Preamp for line or Phono output
• Yamaha piano black finish that shows off your style and your records

DISCOVER TRUE SOUND WITH VINYL
There's nothing like the nostalgic sound of vinyl to connect you with the music. Experts in sound, Yamaha boasts an enviable back-catalogue of Hi-Fi products that have shaped the way we listen to music. Some products have gone on to achieve iconic and even legendary status in Hi-Fi circles - touted for their quality, innovation, and trademark sound.
The TT-S303 signals a return of the Yamaha turntable - drawing inspiration and expertise from the company's unsurpassed musical roots.

ICONIC SOUND
Each component of the TT-S303 was carefully chosen to contribute to rich, uncompressed reproduction. Enjoy superior sound thanks to the belt drive, which reduces vibration. The straight tonearm is made for stable tracking, and an external DC power supply cuts electronic interference. The result is an unadulterated sound.

DESIGNED FOR HI-FI
The TT-S303 was designed with a sleek, minimalist appeal that elevates the look of your Hi-Fi setup.
Pair the TT-S303 with a MusicCast stereo receiver to add music streaming capabilities.

BUILT-IN PRE-AMP
Head-spinning simplicity. Designed with a built-in phono EQ amplifier, you have the option of connecting to a line input on an amp without a phono stage, or even to active speakers!
Alternatively, if you want to utilize the phono stage of your amplifier, switch the TT-S303 to phono output mode for the perfect pairing with your favorite amp.

What to expect in the box:

• TT-S303 Turntable

Product Details:

• Turntable
• Drive Method: Belt drive
• Motor: DC motor
• Rotation Speed: 33-1/3 rpm, 45 rpm
• Rotation Speed Variation: ±2%
• Wow And Flutter: 0.2%
• Platter: Aluminum die-cast (Diameter 30 cm)
• Output Level: 140 mV (-17 dBV, with RIAA EQ), 2.5 mV ± 3 dBV (without RIAA EQ, 1 kHz, 3.54 cm / sec)
• Signal To Noise Ratio: 67 dB or higher (A-weighted, 20 kHz, LPF)
• Tonearm
• Tonearm: Static balance straight tonearm
• Effective Arm Length: 223.5 mm
• Overhang: 19 mm
• Stylus Pressure Adjustment Range: 0-4 g
• Acceptable Cartridge Weight: 15.5-19 g (including headshell)
• Attached Cartridge
• Cartridge Type: MM type
• Output Voltage: 2.5 mV (1 kHz, 3.54 cm / sec)
• Stylus Pressure: 3.5 ± 0.5 g
• Cartridge Weight: 5.0 ± 0.3 g
• Cartridge Height: 17.0 ± 0.7 mm
• Headshell Weight: 10 g (including screws, nuts and wires)
• Audio Specifications
• Output Terminal: RCA: 1 (PHONO)
• General
• Power Consumption: 1.5 W
• Standby Power Consumption: 0.1 W
• Dimension (W×H×D): 17-3/4” x 5-3/8” x 14-1/2”
• Weight: 10.6 lbs.
