Pro-Ject RPM 9 Carbon High-End Turntable With 9“ Evo Tonearm

Pro-Ject RPM 9 Carbon High-End Turntable With 9“ Evo Tonearm - Pro-Ject

Due to extensive research and development, we now lift our classic RPM design to an even higher level. The RPM 9 Carbon uses a new extra heavy chassis which features a special CNC machined MDF plate that incorporates hard resin coated steel pellets to form an extra heavy precise sandwich construction. A special complex heat treatment and a carbon surface coating ensure superior low resonance levels. The mass-loaded chassis is effectively decoupled from its surface using magnetic feet.

Combined with a new special polished aluminum platter with internal TPE damping and a vinyl layer on top, the inverted ceramic main bearing delivers an absolute stable turntable speed with extra low rumble. The extra heavy outboard motor unit is equipped with a precise motor control and features a built-in switch between 33 & 45 rpm. Last but not least the no compromise 9“ EVO tonearm with conical carbon-fiber arm tube and inverted bearing design ensures perfect tracking, even with demanding cartridges.

Features:

• Advanced sandwich construction of plinth with combination of MDF, carbon fiber and steel pellets
• Plinth manufactured with thermo treatment
• Mass loaded sub chassis design with magnetic feet
• Inverted main bearing with ceramic ball/plate
• 7,2kg acoustically inert aluminum platter with TPE damping and vinyl mat on the top
• DC power supply with AC motor
• Precise DC driven AC generator (Speed Box) built-in
• Electronic speed control with 33/45 rpm switching
• Outboard motor construction with massive steel base
• Pre-mounted 9“ Evolution tonearm
• 5P Connect it Phono CC cable with RCA plugs (XLR available as an option)
• Handmade in Europe

Specs

• Nominal speeds: 33/45 r.p.m.
• Speed variance: ±0,1 %
• Wow and flutter: ±0,06 %
• Signal to noise: 73dB
• Effective tonearm mass: 8g
• Effective tonearm length: 9 ” (230mm)
• Overhang: 18mm
• Power consumption: 12W max / <0,3W standby
• Outboard power supply: 15V DC / 1,6A AC, 90-264V AC, 47 – 63Hz
• Weight: 16.5 kg
• Dimensions: 32.5 × 44 × 18 cm
• Cartridge: None
