Pro-Ject Record Box E USB Phono Pre-amp - Pro-Ject
Record Box E USB is pure vinyl listening pleasure, plus recording functionality to you PC or Mac
Record Box E is an high-quality phono preamplifier, that offers the possibility to convert your valuable LP records into computer music data. Record Box E accepts both MM & MC cartridges and gives audiophile music experience at an entry-level price. The integrated A/D converter operates with Windows and MAC operating systems and connects via USB to your computer. Therefore your valuable vinyl collection can be digitized, especially for use in portable music players.
Advanced circuitry and SMD construction keep noise and distortion at a surprisingly low level. A built-in internal shielding and an outboard DC power supply leave no risk for external interference. Because of its small casing, Record Box E can be placed near the turntable. Input and output sockets are gold-plated for preservation of quality. Record Box E can be connected easily to a line-level input like CD, Aux, or tape of your amplifier.
Features:
- Amplification and RIAA equalization for MM & MC
- Design principle inspired by Dr. Sykora
- Digitalization of vinyl for recording direct to USB with suitable recording programs
- Automatic recognition, no additional drivers needed
- Runs on Windows®, Mac OS® & Linux operating systems
- SMD circuitry with special low noise components
- Internal metal shielding
- Small size allows installation close to record player
- Gold plated RCA connection sockets
- Outboard power supply included
- Black or White casing
Specs:
- Input capacitance/input impedance: MC: 100 ohms/120 pF (low output MC) MM: 47kohms/120 pF (MM or high output MC)
- Gain, MM / MC: 40 dB / 60 dB
- Output voltage typically: 300 mV/1 kHz bei 3 mV/1 kHz (MM) oder 0.3 mV/1 kHz (MC)
- Max. Output: 9,5 V (1 kHz)
- Noise floor MM / MC: 94 dB (A weighted) / 75 dB (A weighted)
- THD MM / MC: <0,01% / <0,05%
- RIAA-equalization curve accuracy: 20 Hz - 20 kHz / max. 0.5 dB
- A/D converter: Burr Brown PCM2904 16-Bit Delta Sigma
- Sampling rates: 32, 44,1 and 48 kHz
- USB output: 5 pin Mini b Buchse
- USB signal: digital serial data protocol USB 1.1
- Operating systems: Windows XP®, Windows Vista®, Windows 7®, Windows 8®, Mac OS, Linux
- Input / Line output: 1 pair RCA/Cinch sockets each
- Outboard power supply: 18 V / 500 mA DC, suitable for your country's mains supply
- Power consumption: 100 mA DC
- Dimensions W x H x D (D with sockets): 4.72 x 1.26 x 3.94 (4.53) inches.
- Weight: 0.55 lbs. Without power supply
