Panasonic DP-UB9000P1K Reference 4K Blu-ray Player, Dolby Vision HD Audio

Panasonic DP-UB9000P1K Reference 4K Blu-ray Player, Dolby Vision HD Audio - Panasonic

Enjoy vibrant, theater-worthy video and audio in 4K UHD Blu-ray with 4K upscaling, VOD 4K streaming and more. Plus, pure audio performance with analog audio circuits that include a high-performance D/A converter and XLR balance.

Reference-Class 4K Blu Ray Player
The ultimate home theater experience; spectacular, cinema-level video and audio with higher-than-ever definition and robust connectivity, compatible with four 4K/HDR formats.

Cinema-Worthy Video
Experience the finely nuanced colors and rich, detailed images that film creators intended, with precise chroma processing, with the Panasonic Hollywood Cinema Experience (HCX) Processor.

Future-Proofed Picture Quality
Connect with vibrant, hi-res images in 4K/HDR formats: HDR10+, HDR10, Dolby Vision, and Hybrid Log-Gamma (HLG).

Unique Audio Technologies for Rich Sound Reproduction
High-performance D/A converter and a balanced XLR analog audio circuits have a dedicated audio power supply; alumite-treated aluminum chassis has high rigidity and a lower center of gravity to reduce vibration.

Compatible with Multiple Audio Formats
Plays WAV/FLAC/WMA/AIFF/AAC/MP3 formats, DSD (2.8 MHz/5.6 MHz/11.2MHz) and ALAC music files.

What to expect in the box:

• DP-UB9000P1K Reference 4K Blu-ray Player, Dolby Vision HD Audio

Product Details:

• General
• Surround Sound Decoding
• Dolby Digital Plus
• Dolby TrueHD
• DTS-HD High Resolution Audio
• DTS-HD Master Audio
• 4K Ultra HD: Yes
• 3D Capable: Yes
• Internet Movie Streaming: Yes
• Built-in Wi-Fi: 802.11 a/b/g/n/ac
• Smartphone App Control: No
• DVD Video Upconversion: up to 4K
• Multibrand Remote: Yes
• Parts Warranty: 1 Year
• Labor Warranty: 90 Days
• Compatibility
• CD-R Capable: Yes
• CD-R/W Capable: Yes
• SACD Playback: No
• DVD-Audio Playback: No
• Outputs
• Digital Optical Output: 1
• Digital Coaxial Output: 1
• HDMI Outputs: 2
• HDMI Version: 2.0a/1.4a
• Ethernet Ports: Yes
• Analog Audio Outputs: 7.1ch
• 1080p Video Output: Yes
• Component Video Outputs: None
• S-232C Port: None
• Disc & USB Playback
• Blu-ray: UHD BD-ROM, BD-ROM, BD-R, BD-RE, 3D-BD
• DVD: DVD-ROM, DVD-R, DVD-RW, DVD+R, DVD+RW
• CD: CD-Audio, CD-R, CD-RW
• Ultra HD Blu-Ray: Ultra HD Blu-ray provides these key features and advantages over standard Blu-ray.
• 4K Resolution: Ultra HD Blu-ray supports resolutions of up to 3840 x 2160 pixels. That's 4x as many pixels as Full HD televisions, and 27x as many pixels as Standard Definition televisions
• Wider Color Gamut: Ultra HD Blu-ray can display over 75% of the visible color spectrum; this is known as "Wider Color Gamut". That's more than twice the color range of current Ultra-HD TVs.
• HDR (High Dynamic Range): Ultra HD Blu-ray also supports High Dynamic Range (HDR) video. Dynamic range is the difference between the brightest whites and the darkest blacks on screen. HDR means that scenes with high contrast can be shown with much greater clarity and detail.
• Smooth, Realistic Motion: Ultra HD Blu-ray supports progressive frame rates of 24, 25, 50 and 60 frames a second, enabling smoother, more realistic motion.
• Greater Capacity & Speed: Ultra HD Blu-ray Discs will be available in a dual layer 66 gigabyte disc and a triple layer 100 gigabyte disc. Ultra HD Blu-ray can stream video up to a maximum of 108/128 Mbps for 66Gb and 100Gb discs.
• Backward Compatible: Ultra HD Blu-ray players will play all current Blu-ray Disc & DVD content. When connected to a current Ultra-HD TV television, the player will output a standard Ultra-HD TV signal. Ultra HD Blu-ray players will support existing Blu-ray media, as well as provide down conversion and HDR to SDR conversion functionality to match the connected television's capabilities.
• Note: Like standard BD, Ultra HD Blu-ray discs use region codes. The region code on your disc must match the region code on your player, otherwise the disc will not play. This Blu-ray player is region A and DVD region 1. Blu-ray Disc uses the Advanced Access Content System (AACS) to prevent unauthorized recording of copyrighted material.
• Media File Formats
• Video: AVCHD (up to 1920x1080), MKV (up to 3840x2160/30p or 4096x2160/24p), MPEG-2 (up to 3840x2160/30p or 4096x2160/24p), MP4 (up to 3840x2160/30p or 4096x2160/24p)
• Photo: JPEG, MPO
• Music: MP3 (up to 320kbps/48kHz), WMA (up to 385kbps/48kHz), AAC (up to 320kbps/48kHz), ALAC (up to 32-bit/192kHz), AIFF (up to 32-bit/384kHz), FLAC (up to 24-bit/192kHz), WAV (up to 32-bit/384kHz) , DSD (2.8/4.5/11.2MHz)
• Note: A combined total of up to 10,000 files and folders can be displayed as playable data in each folder regardless of their format.
• HCX Processor:
• Chroma Processing: The unit supports up to 4:4:4 chroma subsampling for full color data rendering of ultra high-definition video. This allows the Ultra HD Blu-ray player to offer twice the color range of existing conventional Blu-ray players and 64x higher color expressions, surpassing the digital cinema standard. With 4K high precision processing and upscaling, 4K (4:2.0) image color signals are interpolated into 4K (4:4:4) by an advanced chroma process to give you full, natural textures and depth. As a result, you'll get to enjoy realistic picture quality like never before.
• HDR Optimizer: The HDR Optimizer will display highly bright scenes with smooth gradations based on the luminance information (static metadata) of your playback content. It can even improve high-brightness imaging on HDR-compatible TVs with low peak brightness. Select which type of HDR compatible TV you own - OLED, High Luminance Projector, Basic Luminance Projector, Super High Luminance LCD, Middle/High Luminance LCD, and Basic Luminance LCD.
• HDR-to-SDR: When this unit is connected to a TV that does not support HDR (High Dynamic Range), the player's HDR video output is converted to a SDR (Standard Dynamic Range) video signal. You then can manually adjust the dynamic range of the image to produce the best brightness and contrast.
• HDR Video:
• HDR10: HDR10 is an open standard and currently the most popular HDR format on the market. It supports 10-bit color and 1,000 nits. It uses static metadata at the start of a movie to tell the receiver and your TV that the video content is encoded using HDR.
• HDR10+: HDR10+ is a a new open standard that leverages dynamic metadata to produce enhanced contrast and colors. The HDR10+ technology incorporates dynamic metadata that allows the player to adjust brightness levels on a scene-by-scene or even frame-by-frame basis. By applying individualized tone mapping to each scene, HDR10+ delivers an incredible viewing experience. The picture quality offers an enhanced visual experience with more detailed expressions, brighter shadow areas and more accurate color renderings that stay true to the creator's original intent.
• Dolby Vision: Dolby Vision adjusts brightness, color, and contrast automatically for each scene. It supports 12-bit color and 10,000 nits. Dynamic metadata carries information that maps every image to your TV's display capabilities, so you see more of what the content creator intended. As a result, Dolby Vision delivers incredible brightness, color, contrast, detail, and dimensionality.
• HLG: HLG (Hybrid-Log Gamma) is primarily designed for live video feed and over-the-air broadcasts. It uses no pre-encoded metadata and is backwards compatible with SDR. HLG's native compatibility allows much of today's existing SDR infrastructure to be re-used for HDR in the future.
• Audio Section
• Reference Quality Construction: The Panasonic DP-U9000P-K Ultra HD Blu-ray player offers reference quality construction for audiophile-grade sound that is free from interference, vibration, and noise.
• AC/DC Conversion Circuit: The main power supply, which provides power to the optical drive and video signal processing circuits, generates a variety of low-to-high frequency noises. These occur, for example, when driving the motor during disc playback, accessing memory, and communicating between peripheral circuits. By separating the power for the audio D/A converter and analog output circuit at their origin, the noise effects are greatly reduced. In addition, soft switching control lowers the noise of the power supply itself.
• 10-Line Isolated DC Regulator Circuit: The digital and analog power supplies for the D/A converter are isolated. The analog channel is further separated into 2 channels and 7.1 channels, and for the 2-chanel output, the reference voltage of the left and right channels is isolated, making a 10-line regulator circuit and reducing mutual effects to improve distortion. Moreover, high-quality audio grade electrolytic capacitors are used in the analog channel to minimize noise.
• Low-Noise Op Amps & Audio-Grade Electrolytic Capacitors: The analog circuits for 2 channel and 7.1 channel output are mounted onto special glass-epoxy circuit boards. Together with the use of quality components, such as low-noise operational amplifiers and audio grade electrolytic capacitors, a totally balanced signal transmission is achieved by using differential circuits all the way from the D/A converter output to the XLR output terminal.
• THX Certified Sound: This THX certified Ultra HD Blu-ray player achieves lifelike surround sound the way the director intended. Now, you can enjoy movies in your own home with cinema-level quality.
• Four 32-bit/192kHz ESS DACs with Upsampling: The Panasonic DP-UB900P1K utilizes four 32-bit/192kHz ESS DACS (digital-to-analog converters) that supports high resolution audio (up to 32-bit/384kHz) to reveal both rich and delicate tone in music and vocals. This audiophile-grade 4-DAC configuration can even upsample low res music files up to 32-bit/192kHz (when the Voice Guidance feature is activated, the maximum upsampling frequency will be fixed at 48kHz). Supported Hi-Res music files include ALAC/FLAC (up to 32-bit/192kHz), AIFF/WAV (up to 32-bit/384kHz), and DSD (up to 11.2MHz).
• HDMI Low Clock Jitter Process: The DP-UB9000P1K utilizes a HDMI Low Clock Jitter Process that faithfully reproduces the original sound recorded onto your UltraHD Blu-ray discs, Blu-ray discs, and DVDs for exceptional audio performance.
• Analog & Digital Audio Outputs: In addition to HDMI connectivity, the Panasonic DP-UB900P-K is outfitted with both analog & digital audio outputs. There is a 2ch analog stereo balanced XLR output, a 7.1ch analog unbalanced RCA output, a coaxial (RCA) digital output and optical (toslink) digital output. The balanced (XLR), unbalanced (RCA), and coaxial (RCA) output terminals are gold-plated for excellent signal transfer and resistance to corrosion.
• Balanced (XLR) & Unbalanced (RCA) Outputs: The DP-UB90001K is outfitted with a 7.1ch unbalanced RCA analog audio output that lets you connect to an AV receiver, preamplifier, or processor with a corresponding 7.1ch RCA analog audio input. The "Front" RCA outputs of the 7.1ch analog audio output can also be used for a 2-channel connection to a stereo receiver. In addition, there is a balanced XLR 2ch output for connection of high-quality stereo receivers and integrated amplifiers. A Balanced XLR connection provides better audio quality with less noise.
• Optical & Coaxial Digital Outputs: The Ultra HD Blu-ray player is equipped with a optical (toslink) digital output and coaxial (RCA) digital output. Both digital outputs support Dolby Digital, DTS, & PCM (2ch to 5.1ch) audio signals with a sampling frequency of 48, 96, or 192kHz.
• Surround Sound Decoders: The Panasonic DP-UB9000P1K UHD Blu-ray player has built-in Dolby Digital and DTS surround processors with support for Dolby Digital Plus, Dolby TrueHD, DTS-HD High Resolution, and DTS-HD Master Audio. Dolby Digital Plus, Dolby TrueHD, and DTS-HD are only output via the player's HDMI output. If you have an AV receiver which decodes Dolby Atmos or DTS:X, you will need to set this UHD Blu-ray player's HDMI output to bitstream. It also streams Dolby Atmos movies from built-in apps (service and movie must support Dolby Atmos).
• Sound Effects: The Panasonic DP-UB9000P1K offers a variety of Sound Effects to to improve the audio quality of your movies and music tracks. You can choose between Night Surround, Remaster, or Digital Tube Sound (you can only choose one).
• Night Surround: The Night Surround features lets you enjoy a movie with powerful sound even when the volume is kept low at night. The audio is set in such a way that it can be heard easily.
• Remaster: The Remaster feature gives you brighter sound by increasing the high frequency portion of the audio that is lost during the compression of some audio formats. There are three settings - 1 (for Pop and Rock music) / 2 (for Jazz music) / 3 for Classic music).
• Digital Tube Sound: The Digital Tube Sound feature gives you a warm sound, like that produced by a vacuum tube amplifier. You can choose between one of six settings - 1 (crisp, delicate sound) / 2 (tight, hifi sound) / 3 (soft, rich sound) / 4 (clear, powerful sound) / 5 (distinctive midrange sound) / 6 (soft, enveloping sound).
• Audio Settings: The DP-UB9000P1K offers several audio adjustments to to tailor the sound to your specific application.
• Dialog Enhancer: The Dialog Enhancer feature increases the volume level of the center channel to make it easier to hear dialog and voices over movie sound effects and background music.
• High Clarity Sound: The High Clarity Sound feature stops the digital signal processing (DSP), front-panel display, and video output in order to produce the best audio signal for your high resolution music files without any interference.
• DRC (Dynamic Range Control): DRC (Dynamic Range Control) allows you to listen to a movie at a lower volume without losing clarity of sound. This feature is only available for Dolby Digital, Dolby TrueHD, and Dolby Digital Plus audio signals. DRC can be set to Auto, On, or Off.
• Audio Delay: In some cases when the player is connected to a TV, the audio signal may not synchronize with the video signal. If this occurs, adjust the audio delay time to match the video signal. You can set the audio delay time between 0 msec and 250 msec.
• Network & Internet Content
• Wired or Wireless Network Connection: The Panasonic DP-UB9000P1K Ultra HD Blu-ray player supports a wired or wireless network connection. Via the Ultra HD Blu-ray player's network & internet connection, you can enjoy select online entertainment services, as well as access content on your home network devices.
• Ethernet (LAN) Jack: The Panasonic DP-UB9000P1K is equipped with an Ethernet (LAN) RJ-45 jack for connecting the UHD Blu-ray player to your home network and computer. A 10 Base-T or 100 Base-TX LAN port is required for wired connection to this player.
• WiFi (wireless LAN): The DP-UB9000P1K offers built-in dual-band (2.4/5GHz) WiFi (802.11 b/g/n/ac) that allows you to wirelessly access the Internet and your home network. The player's built-in WiFi provides a wireless network connection for the unit with easy and quick setup. With this feature, you can easily connect to a wireless LAN and enjoy the benefits of networking in a cable-free environment. A wireless connection requires a home network with an 802.11 access point and internet connection. Supports WPS, WEP, and WPA security; a dual-band Gigabit wireless-N or better router is recommended for 4K streaming
• Online Content: The Panasonic DP-UB9000P1K offers access to a variety of online entertainment applications once the player is connected to your home network and the internet. You'll have access to online movie, music, gaming, weather and other applications.
• Movies & Videos: Watch online movies, TV shows, and videos on Netflix, Amazon Video, and YouTube. Content is available in 4K, high-definition, and standard definition.
• Music: Listen to your favorite music and internet radio on Pandora, TuneIn, ShoutCast, and Napster (Rhapsody).
• Other: You all get access to several gaming, kids, health, lifestyle, and weather (including AccuWeather) applications.
• DLNA Certified: DLNA certification allows you to enjoy various content from your home network, such as music (including hi-res), photo, and video (including 4K) files stored on your Windows 7/8/10 PC (or other DLNA Certified media server/Android device) through the Panasonic DP-UB9000P1K. The UHD Blu-ray player can be connected to your compatible PC using a hardwired Ethernet (LAN) connection or WiFi connection (via built-in WiFi).
• Video: AVCHD (up to 1920x1080), MKV (up to 3840x2160/30p or 4096x2160/24p), MPEG-2 (up to 3840x2160/30p or 4096x2160/24p), MP4 (up to 3840x2160/30p or 4096x2160/24p)
• Photo: JPEG, MPO
• Music: MP3 (up to 320kbps/48kHz), WMA (up to 385kbps/48kHz), AAC (up to 320kbps/48kHz), ALAC (up to 32-bit/192kHz), AIFF (up to 32-bit/384kHz), FLAC (up to 24-bit/192kHz), WAV (up to 32-bit/384kHz) , DSD (2.8/4.5/11.2MHz)
• Miracast: Miracast is a "screen mirroring" function which lets you wirelessly send the display from your compatible Windows 8.1+ or Android 4.2+ device (with support for Miracast) through the UHD Blu-ray player and to your TV. This allows you to view pictures and videos that are playing on your compatible Windows or Android device on your TV screen.
• BD-Live: BD-Live technology allows you to download and stream bonus content such as additional scenes, shorts, trailers, movie-based games, and more from a broadband internet and home network connections (fees may apply). The player features an Ethernet port and built-in WiFi to connect to the internet via your home network, and features USB (type-A) port for additional storage.
• Convenience & Remote Features
• Quick Start: Quick Start speeds up the load time on movies, so discs start faster after they're inserted into the UHD Blu-ray player. The Panasonic Ultra-HD Blu-ray player has a start-up time of approximately 4.7 seconds in Quick Start mode (24.3 seconds in normal mode). In Quick Start mode, it takes approximately 30.1 seconds for a Blu-ray disc to begin playback (35.7 seconds in normal mode).
• Remote Control: The included IR remote control provides full wireless operation of the Ultra HD Blu-ray player. You can also program the included IR remote to operate basic functions of select brands of TVs (including Panasonic, LG, Samsung, Sony, and Vizio). Programmable control functions include Power On/Off, Volume Up/Down, and AV Input.
• HDMI CEC (VIERA Link): HDMI CEC (VIERA Link) links select operations of this player with other VIERA Link and HDMI CEC compatible devices that are connected to one another via HDMI. Linked operations included Auto Power On/Off and Auto Input Switching. When you power your HDMI-connected TV on or off, the player will also turn on or off. In addition, when you begin playback on the UHD Blu-ray player, your HDMI-connected TV will automatically switch to the appropriate input.
• Gapless Playback: Gapless playback is supported for FLAC, WAV, AIFF, and DSD music files on a USB MSC device or a DLNA network device. Gapless playback is not supported if there are more than 100 songs contained in a single folder.
• Photo Slideshow: Play a slideshow of photos (JPEG files only) with music (MP3 or FLAC music files) in the background from a USB MSC device or DLNA network device.
• Parental Control: The Panasonic offers Parental Control settings to limit Ultra HD BD, BD, and DVD content according to the age of the users. You can also block access to network and internet content.
• Voice Guidance: Voice Guidance reads aloud various on-screen information, such as menu items, explanatory text, and currently-selected items. When Voice Guidance is activated, the player is restricted to PCM and only offers 48kHz upsampling.
