JBL Stage XD-5 2-way 5.25" Waterproof Loudspeaker (pair)

JBL Stage XD-5 2-way 5.25" Waterproof Loudspeaker (pair) - JBL

Featuring a 5.25" (130mm) Polypropylene Graphite Filled Cone Woofer and a 1” (25mm) Aluminum tweeter with an acoustic lens and HDI™ waveguide, the Stage XD-5 all-weather speaker is perfect for an outdoor location when protection from the weather is a requirement. Stylish design and mounting flexibility make it equally at home indoors in a variety of applications. Elements including acoustic lens tweeters, and patented High-Definition Imaging (HDItm) waveguide geometry have been incorporated into the design to ensure that the sound is clear and accurate.

Product details:

IP67 Waterproof Rating
This rating provides protection from the harshest of outdoor conditions.  Combined with their high-level water-ingress protection indicated by the second digit (7), IP67-rated enclosures can withstand water hoses, jet sprays, and momentary water immersion. Rest assured, IP67-rated enclosures are guaranteed to function in indoor, outdoor, wet, and demanding industrial and commercial settings.

High-Definition Imaging (HDI™) Waveguide
This optimized geometry results in smooth dispersion and low distortion. HDI Waveguide technology is the result of intense research into the nuances of waveguide design. The waveguide is made up of a lightweight polymer diaphragm that improves high-frequency extension.

Polypropylene Graphite Filled Cone Woofer
Graphite-injected polypropylene is a composite material of polypropylene and graphite that is stiffer and stronger than regular polypropylene film.
Why graphite? Graphite is a mineral composed of stacked sheets of carbon atoms with a hexagonal crystal structure. It is the most stable form of pure carbon under standard conditions. Graphite is very soft, has a low specific gravity, is relatively non-reactive, and has high electrical and thermal conductivity.

Rotatable Logo For Horizontal And Vertical Applications.
Included wall-mount bracket allows for easy installation and angle adjustment
Zero Bezel Magnetically Attached Grilles

General Specifications:

• Product Type: 2-way 5.25" Indoor/Outdoor All Weather Loudspeaker
• Weatherproof rating: IP67
• Tweeter: 1" aluminum dome with High-Definition Imaging (HDI™) waveguide
• Woofer: 5.25" polypropylene graphite filled cone
• Nominal Impedance: 6ohms
• Sensitivity (2.83V@1m): 86dB
• Recommended Amplifier Power: 20-100W RMS
• Frequency Response (-6dB On-Axis): 75Hz-25kHz
• Crossover Frequency: 2500K
• Operating Temperature: 32° F (0° C) to 113° F (45° C)
• Product Dimensions: 6.37" high x 7.17" wide x 6.37" deep (mounted horizontally)
• Product Weight: 2.3lbs.
• Wall mount adds: 2.8" to depth

What to expect in the box:

• (2) JBL XD-5 outdoor loudspeakers
• (2) Grilles
• (2) Wall-brackets
• (2) Speakers brackets (hex-nut attached)
• (2) Locking-collars
• (8) Self-adhesive rubber feet
• Pry-tool
• Owner's Manual
• Warranty Card
