The JBL SCL-5 Two-way 7-inch In-Ceiling Loudspeaker brings JBL Synthesis cinema technology to a discreet architectural design engineered for premium immersive audio systems. Designed for off-axis listening applications, the SCL-5 combines a 7-inch Advanced Aluminum Matrix cone woofer with JBL's 2409H annular-ring compression driver and an offset High-Definition Imaging horn, providing controlled dispersion and consistent performance even when the loudspeaker cannot be positioned directly above the primary listening area.
A rotatable angled baffle allows the acoustic output to be aimed toward the listening position, making the SCL-5 exceptionally versatile for Dolby Atmos height channels, in-ceiling LCR systems, and surround applications. JBL's Cat Claw mounting system simplifies installation, while Boundary Proximity Control helps compensate for placement near room boundaries. Paintable round and square zero-bezel magnetic grilles are both included, allowing the finished installation to blend naturally with the surrounding ceiling.
Key Features & Innovations
High-performance JBL Synthesis in-ceiling design — the JBL SCL-5 Two-way 7-inch In-Ceiling Loudspeaker is engineered for medium to large immersive audio systems where architectural integration must be combined with high-performance cinema sound.
7-inch Advanced Aluminum Matrix woofer — the cast-frame 180mm woofer uses JBL's Advanced Aluminum Matrix cone construction and a low-distortion neodymium motor structure for clean, controlled low-frequency and midrange reproduction.
2409H annular-ring compression driver — JBL's 1-inch Teonex diaphragm compression driver provides high output capability, excellent transient response, and the clarity associated with JBL's professional and Synthesis loudspeaker designs.
Offset High-Definition Imaging horn — the compression driver is coupled to JBL's patented HDI horn geometry, providing controlled dispersion and consistent tonal balance over a wide listening area.
Angled, rotatable acoustic baffle — the woofer and horn assembly is angled approximately 45 degrees and can be rotated during installation, allowing the loudspeaker's coverage to be directed toward the listening area rather than simply firing straight down.
Designed for off-axis listening — the SCL-5 provides broad 120-degree horizontal high-frequency coverage with controlled vertical dispersion, making it particularly effective when ceiling placement is offset from the listening position.
Versatile immersive-audio applications — JBL specifically designed the SCL-5 for use as height, in-ceiling LCR, and surround channels, allowing it to support a wide range of premium architectural theater layouts.
Boundary Proximity Control — an onboard compensation switch helps optimize tonal balance when the loudspeaker must be installed close to a wall or other room boundary.
Patented Cat Claw mounting system — JBL's retractable mounting mechanism simplifies installation by helping secure the loudspeaker in position before final tightening.
Round and square grilles included — zero-bezel magnetic round and square grilles are both supplied and can be painted to coordinate with the surrounding ceiling.
FAQ — JBL SCL-5
Can the JBL SCL-5 be used for Dolby Atmos height channels?
Yes. Height-channel use is one of the SCL-5's primary applications. Its angled and rotatable driver assembly allows the loudspeaker's acoustic output to be aimed toward the listening area, making it especially useful when an Atmos speaker cannot be positioned directly above the seats.
Can the SCL-5 be used as an in-ceiling LCR speaker?
Yes. JBL specifically identifies in-ceiling LCR as one of the SCL-5's intended applications. The directional baffle and controlled HDI horn dispersion allow the speaker to direct sound toward the listening position when installed in the ceiling ahead of the seating area.
How much amplifier power is recommended for the SCL-5?
JBL recommends amplifier power between 25 and 125 watts RMS. The loudspeaker has a nominal impedance of 6 ohms and a sensitivity of 86dB at 2.83V/1m.
Does the SCL-5 include a backbox?
The standard SCL-5 is an open-back architectural loudspeaker and does not require an integrated enclosure. JBL provides specifications for minimum enclosure volumes when an installer needs to construct or incorporate a controlled enclosure around the speaker.
Can the SCL-5 be aimed toward the listening position?
Yes. The loudspeaker uses an angled baffle that can be rotated during installation. This allows the installer to orient the woofer and HDI horn assembly toward the primary listening area for improved coverage and more precise integration.
Does the SCL-5 come with both round and square grilles?
Yes. JBL includes both round and square zero-bezel magnetic grilles with each SCL-5. Both grilles are paintable, allowing the installer to choose the appearance that best matches the room.
