Dual CS 518 Manual Belt-Drive Turntable With Built-In Phono Preamp - Dual
For the true Vinyl Enthusiast, the CS 518 is equipped with a twin gimbal tonearm design using pivot ball-bearings for optimal precision.
This superior tonearm has the ability to guide even high end pickups with the greatest degree of precision and reliability.
The Ortofon 2M Red pickup and a switchable MM-phono preamplifier are an integral part of this ready to run package.
DETAILS:
Plinth: Solid MDF:
- Folded MDF construction with a black vinyl veneer
- Elastomer vibration absorber integrated inside the feet
- Removable dust cover
Platter: Aluminum Die-cast
- Precise aluminum die-cast
- Heavy rubber mat for resonance damping
- Solid platter bearing with a hardened steel spindle in a brass bushing
Tonearm: Twin Gimbal Design
- Straight, statically balanced
- Solid aluminum construction with precision pivot ball-bearing
- Adjustable tracking force and anti skating
Drive: DC- Motor / Belt
- Low vibration DC-Servo-Motor
- Rubber mountings for vibration decoupling
- Precision cut belt for lower wow & flutter
TECHNICAL SPECIFICATIONS:
- Motor
- Drive: Belt
- Speed settings: 33/45/78
- Wow & Flutter: < ±0,1 % (DIN WTD)
- Tonearm
- Auto-Start/-Stop-Function: No
- Bearing: 4 x Pivot ball-bearing / twin gimbal mounting
- Effective length: 221.5 mm
- Offset Angle: 25.6°
- Overhang: 19 mm
- Type: statically balanced
- Stylus Pressure Range: 0 g bis 4 g
- Cartridge Weight Range: 5 g bis 9 g
- Factory installed pick up: Ortofon 2M Red
- Platter
- Material: Aluminum die-cast
- Mat: Rubber 2.5 mm
- Bearing: Hardened steel spindle Brass bushing
- Diameter: 305 mm
- Weight (incl. Mat): 850 g
- Plinth:
- Material: MDF, folded
- Surface finish: White / Black
- Feet: Ø 62 mm / Elastomer
- Connection: RCA socket
- Connection to Phono Input: Yes
- Connection to Line Input: Yes
- Digital Output: No
- Dimension, closed dustcover: 435 x 367 x 145 mm
- Dimension, open dustcover: D: 415 mm / H: 400 mm
- Weight: 5.9 kg
- Power plug AC / DC: External power supply
