Audio-Technica AT-VM750xSH VMx MM Phono Shibata Cartridge

VMx 700 Series • Nude Shibata Stylus • Solid Boron Cantilever • Dual Moving Magnet • PCUHD Coils • Die-Cast Aluminum Body • ½-Inch Mount

Premium VMx Moving Magnet Cartridge with Nude Shibata Stylus

The Audio-Technica AT-VM750xSH VMx MM Phono Shibata Cartridge combines Audio-Technica’s advanced VMx Dual Moving Magnet generator architecture with a nude Shibata stylus and solid boron cantilever for highly detailed analog reproduction. The Shibata profile provides an extended groove-contact area designed to accurately trace complex high-frequency information while maintaining excellent performance across the record surface.

As part of the premium VMx 700 Series, the cartridge incorporates PCUHD coil conductors, paratoroidal coil construction, a center shielding plate, threaded mounting holes and a rigid die-cast aluminum body. These refinements help improve electrical efficiency, channel separation and resonance control while simplifying cartridge installation. With a 3.7 mV output, the AT-VM750xSH is designed for high-quality moving-magnet phono stages using standard 47 kΩ loading.

Highlights & Benefits

  • Nude Shibata Stylus — The 2.7 × 0.26 mil Shibata profile provides an extended contact area with the groove walls for excellent high-frequency tracing and detailed reproduction.
  • Solid Boron Cantilever — A rigid 0.28 mm solid boron cantilever provides low moving mass and rapid response to subtle groove modulation.
  • PCUHD Coil Conductors — Pure Copper Ultra High Drawability wiring and optimized coil construction help improve signal transmission and transient response.
  • Die-Cast Aluminum Body — The rigid premium housing helps control unwanted vibration and resonance around the cartridge generator.
  • Threaded Mounting Holes — Integrated M2.6 threads simplify cartridge installation by allowing mounting screws to secure directly into the cartridge body.

Technology & Design

VMx Dual Moving Magnet Generator — Audio-Technica positions separate magnets to correspond with the left and right sides of the stereo record groove, reproducing the geometry of a stereo cutter head for precise channel information.

Paratoroidal Coil Construction — The generator uses two coils per channel arranged in a paratoroidal configuration. A center shielding plate positioned between the channels helps reduce electrical crosstalk and preserve stereo separation.

Shibata Groove Contact — Originally developed to reproduce demanding high-frequency groove information, the Shibata profile maintains an elongated contact area against the groove wall for accurate tracking and refined detail retrieval.

Interchangeable VMx Stylus Platform — The AT-VM750xSH uses the AT-VMN50xSH replacement stylus and is part of Audio-Technica’s interchangeable stereo VMx stylus system, providing additional options for future stylus-profile changes.

FAQ — Audio-Technica AT-VM750xSH

What type of phono preamp does the AT-VM750xSH require?

The AT-VM750xSH is a moving-magnet cartridge designed for an MM phono input or compatible MM phono preamplifier. Audio-Technica specifies a recommended load impedance of 47 kΩ and capacitance of 150–250 pF.

What tracking force should I use with the AT-VM750xSH?

Audio-Technica specifies a tracking-force range of 1.8 to 2.2 grams, with 2.0 grams as the standard recommended setting.

What replacement stylus does the AT-VM750xSH use?

The direct replacement is the Audio-Technica AT-VMN50xSH nude Shibata stylus. The cartridge is also part of the interchangeable stereo VMx stylus platform.

How does the AT-VM750xSH differ from the AT-VM760xSL?

The AT-VM750xSH uses a nude Shibata stylus and has a specified frequency response extending to 27 kHz. The flagship AT-VM760xSL instead uses Audio-Technica’s Special Line Contact stylus and extends its specified response to 30 kHz. Both use solid boron cantilevers and premium aluminum VMx 700 Series bodies.

Why Buy From Us

  • Authorized Audio-Technica Dealer
  • 5% Reward Points on Every Purchase
  • Expert Cartridge, Tonearm and Phono-Stage Matching Assistance
  • Professional Cartridge Installation and Turntable Setup Available

Audio-Technica AT-VM750xSH Specifications

Product Type
Moving Magnet phono cartridge
Series
VMx 700 Series
Cartridge Type
VM stereo / Dual Moving Magnet
Frequency Response
20–27,000 Hz
Output Voltage
3.7 mV at 1 kHz, 5 cm/sec
Channel Separation
26 dB at 1 kHz
Output Balance
1.0 dB at 1 kHz
Tracking Force Range
1.8–2.2 g
Standard Tracking Force
2.0 g
Stylus Type
Nude Shibata
Stylus Curvature Radius
2.7 × 0.26 mil
Cantilever
0.28 mm / 0.011 in solid boron
Vertical Tracking Angle
20°
Coil Construction
Paratoroidal
Coil Conductor
PCUHD copper
Coil Impedance
3.2 kΩ at 1 kHz
DC Resistance
750 Ω
Coil Inductance
480 mH at 1 kHz
Recommended Load Impedance
47 kΩ
Recommended Load Capacitance
150–250 pF
Static Compliance
20 × 10⁻⁶ cm/dyne
Dynamic Compliance
7 × 10⁻⁶ cm/dyne at 100 Hz
Cartridge Body
Die-cast aluminum
Center Shield Plate
Yes
Mounting
Standard ½-inch mount
Threaded Mounting Holes
M2.6 × 2
Dimensions
17.5 × 18.3 × 29.0 mm
0.69 × 0.72 × 1.1 in (H × W × D)
Weight
8.8 g / 0.31 oz
Replacement Stylus
AT-VMN50xSH
Brand
Audio-Technica

What's in the Box

  • 1 × Audio-Technica AT-VM750xSH VMx Cartridge
  • 1 × Preinstalled AT-VMN50xSH Nude Shibata Stylus
  • 2 × 10 mm M2.6 Cartridge Installation Screws
  • 2 × 8 mm M2.6 Cartridge Installation Screws
  • 2 × 5 mm M2.6 Cartridge Installation Screws
  • 2 × Washers
  • 1 × Non-Magnetic Screwdriver
  • 1 × Stylus Brush
  • Product Documentation

Headshell, turntable, phono preamplifier, alignment tools, tracking-force gauge and other system components are sold separately unless otherwise specified.
