Arcam AVA35 AV Amplifier

$6,999.95
$6,999.95
Availability: In Stock
Have Questions or Need Advice?
Audiolab Advisor
Consult with a System Expert
From our PA Showroom

Free Shipping, no minimum!

60-Day Returns

Have a Trade-In? Fill Out Our Form.

ARCAM

Arcam AVA35 AV Amplifier

16-Channel AV Processing • 9 Channels of Class G Amplification • 145W/Ch into 8Ω • Matrix Channel Assignment • Dirac Live • Dolby Atmos • DTS:X • IMAX Enhanced • AURO-3D • HDMI 2.1a 8K

Flagship Class G Home Cinema Performance with 16-Channel Processing

The Arcam AVA35 AV Amplifier represents the flagship integrated home cinema solution in ARCAM's Radia AV range, combining sixteen channels of immersive audio processing with nine channels of ARCAM Class G amplification. Engineered in Cambridge, UK, the AVA35 is designed for listeners who demand exceptional musical performance alongside reference-quality movie reproduction, providing flexible speaker configuration, sophisticated room correction and substantial power from a single premium component.

Matrix Channel Assignment allows amplifier and processing channels to be allocated according to the needs of the system, while Dolby Atmos, DTS:X, IMAX Enhanced and AURO-3D provide comprehensive immersive-audio support. Seven HDMI 2.1a inputs handle compatible 8K/60Hz and 4K/120Hz sources, while Dirac Live Room Correction, high-resolution network streaming, Roon Ready support and ARCAM's Radia AV Control app make the AVA35 equally capable as a cinema processor and a high-performance music system.

Highlights & Benefits

  • Nine Channels of ARCAM Class G Power — ARCAM's signature Class G architecture combines high power capability with increased efficiency and low crossover distortion for both music and cinema playback.
  • 16-Channel Processing — Extensive multichannel processing allows sophisticated immersive speaker layouts and future expansion with compatible external amplification.
  • Matrix Channel Assignment — Amplifier channels can be reassigned to create customized speaker configurations, including additional surround, height, subwoofer and multi-zone applications.
  • Dirac Live Room Correction — Included Dirac Live calibration optimizes the speaker system for the room, with optional upgrade paths to Dirac Live Bass Control and Dirac Live Active Room Treatment.
  • HDMI 2.1a with 8K & 4K/120 — Seven HDMI inputs support current high-bandwidth video formats and gaming technologies including VRR, ALLM, HDR10+, Dolby Vision and eARC.

Technology & Design

ARCAM Class G Amplification — The AVA35 uses nine channels of ARCAM's proprietary Class G amplification, a topology designed to increase efficiency while maintaining the sonic characteristics, control and low distortion associated with high-quality linear amplification.

Matrix Channel Assignment — Unlike fixed amplifier architectures, the AVA35 allows channels to be reassigned throughout the system, giving installers greater flexibility when configuring surround, height, subwoofer and additional-zone requirements.

High-Performance DAC Architecture — ARCAM equips the AVA35 with the same advanced DAC architecture developed for its premium stereo components, reinforcing the amplifier's focus on high-quality two-channel music reproduction as well as home cinema.

Expandable Dirac Platform — Dirac Live Room Correction is supported as standard, while compatible upgrades to Dirac Live Bass Control and Dirac Live Active Room Treatment provide increasingly sophisticated control over low-frequency behavior and whole-system interaction.

FAQ — Arcam AVA35

How many channels does the ARCAM AVA35 amplify?

The AVA35 contains nine channels of built-in Class G amplification while providing processing for up to sixteen channels. Additional external power amplifiers can be used when the system requires more amplified channels.

How much power does the AVA35 produce?

ARCAM rates the AVA35 at 145 watts per channel into 8 ohms with two channels driven and 110 watts per channel into 8 ohms with seven channels driven. Into 4 ohms, ARCAM specifies 200 watts with two channels driven and 130 watts with seven channels driven.

Does the AVA35 include Dirac Live?

Yes. Dirac Live Room Correction is supported. Dirac Live Bass Control and Dirac Live Active Room Treatment are available as optional upgrade paths for more advanced system optimization.

Does the AVA35 support 8K and 4K/120Hz?

Yes. Its HDMI 2.1a platform supports compatible video resolutions up to 8K/60Hz or 4K/120Hz, along with VRR, ALLM, eARC, Dolby Vision, HDR10+ and other modern HDMI features.

Why Buy From Us

  • Authorized ARCAM Dealer
  • 5% Reward Points on Every Purchase
  • Expert Home Theater Design and System-Matching Assistance
  • Professional Installation, Speaker Calibration and Dirac Live Setup Available

Arcam AVA35 Specifications

Product Type
Flagship integrated AV amplifier
Maximum Processing Channels
16
Amplifier Channels
9
Amplifier Class
ARCAM Class G
Channel Assignment
Matrix Channel Assignment; all channels reassignable with subwoofer assignment available on designated channels
Power — 8Ω / 2 Channels
145W per channel
20Hz–20kHz, 0.5% THD
Power — 4Ω / 2 Channels
200W per channel
1kHz, 0.5% THD
Power — 8Ω / 7 Channels
110W per channel
20Hz–20kHz, 0.5% THD
Power — 4Ω / 7 Channels
130W per channel
1kHz, 0.5% THD
Harmonic Distortion
0.004% at 80% power, 8Ω, 1kHz
Room Correction
Dirac Live Room Correction
Dirac Upgrades
Dirac Live Bass Control and Dirac Live Active Room Treatment compatible
Dolby Atmos
Yes
Dolby TrueHD
Yes
DTS:X
Yes
DTS-HD Master Audio
Yes
IMAX Enhanced
Yes
AURO-3D
Yes
MPEG-H
Supported
HDMI Inputs
7
HDMI Outputs
3 total
2 × Zone 1 + 1 × Zone 2
HDMI / HDCP Version
HDMI 2.1a / HDCP 2.3
Maximum Video Resolution
8K / 60Hz
4K High Frame Rate
Up to 4K / 120Hz
Variable Refresh Rate
VRR supported
Auto Low Latency Mode
ALLM supported
eARC / ARC
Supported on Zone 1 HDMI Output 1
HDR Support
HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision and HLG
Analog Audio Inputs
3 × stereo RCA pairs
Coaxial Digital Inputs
2 × RCA
Up to 24-bit / 192kHz
Optical Digital Inputs
2 × TOSLINK
Up to 24-bit / 96kHz
Preamplifier Outputs
16 × RCA
Balanced Pre-Out
No XLR preamplifier outputs
Pre-Out Maximum Level
2V RMS per channel
Streaming Resolution
Up to 24-bit / 192kHz
Roon
Roon Ready
Spotify Connect
Supported
TIDAL Connect
Supported
Qobuz Connect
Supported
Apple AirPlay
Supported
Google Cast
Supported
UPnP
Supported
Internet Radio / Podcasts
Supported through Radia AV platform
Bluetooth Version
Bluetooth 5.4
Bluetooth Features
A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio and Auracast
Wi-Fi
802.11 a/b/g/n/ac, 2.4GHz / 5GHz
Control App
ARCAM Radia AV Control app
Remote Control
Backlit Bluetooth remote
Front Display
6.5-inch high-resolution color display
Maximum Power Consumption
900W
Idle Consumption
93W
Standby Consumption
2W default / 0.4W low-power mode
Dimensions
17.0" W × 18.1" D × 6.7" H
432 × 459.1 × 170 mm
Net Weight
50.0 lbs. / 22.7 kg
Packed Weight
64.8 lbs. / 29.4 kg
Engineering
Engineered in Cambridge, UK
Series
ARCAM Radia AV
Finish
Black with Radia yellow accents
Brand
ARCAM

What's in the Box

  • 1 × Arcam AVA35 AV Amplifier
  • 1 × Backlit Bluetooth Remote Control
  • 2 × AAA Batteries
  • 1 × Measurement Microphone
  • 1 × 5-Meter USB Cable
  • 1 × Rear-Panel Cowl
  • Region-Specific AC Power Cord(s)
  • Quick Start Guide
  • Important Safety Instructions
