Product Type
Stereo integrated amplifier with Bluetooth, DAC and MM phono stage
Continuous Power into 8 Ohms
50 watts per channel, 20Hz–20kHz, both channels driven, 0.5% THD
Continuous Power into 4 Ohms
75 watts per channel at 1kHz, both channels driven, 0.5% THD
Harmonic Distortion
0.003% at 80% power, 8 ohms, 1kHz
Analog Line Inputs
3 × stereo RCA pairs
Analog Input Frequency Response
20Hz–20kHz, ±0.2dB
Analog Signal-to-Noise Ratio
106dB, A-weighted, referenced to 50 watts and 1V input
Phono Input
1 × stereo RCA moving-magnet input with ground terminal
Phono Input Impedance
47 kilohms + 100pF
Phono Frequency Response
20Hz–20kHz, ±1dB referenced to the RIAA curve
Phono Signal-to-Noise Ratio
80dB, A-weighted, referenced to 50 watts and 5mV input
Digital-to-Analog Converter
ESS ES9018K2M
Coaxial Digital Inputs
2 × RCA S/PDIF
Optical Digital Input
1 × Toslink
Supported Digital Sample Rates
44.1, 48, 88.2, 96, 176.4 and 192kHz
Supported Digital Bit Depths
16-bit and 24-bit
Digital Frequency Response
20Hz–20kHz, ±0.2dB with Filter 1
Digital Signal-to-Noise Ratio
109dB, A-weighted, referenced to 50 watts and 0dBFS
Bluetooth Version
Bluetooth 5.4
Bluetooth Operation
A2DP sink and source, AVRCP and Bluetooth Low Energy
Bluetooth Audio Support
SBC, AAC, aptX, aptX HD, aptX Lossless and Snapdragon Sound
Auracast
Supported for compatible wireless headphones and speakers
Bluetooth Frequency
2,400MHz–2,483.5MHz
Bluetooth Transmitter Power
Less than 20dBm
Headphone Output
Front-panel wired headphone output
Headphone Output Level
2.5V RMS into 32 ohms; 5V RMS into 300 ohms
Headphone Load Range
16 ohms–2 kilohms
Preamplifier Output
1 × variable stereo RCA output
Speaker Outputs
1 × stereo pair of binding posts
Recommended Speaker Impedance
4–16 ohms
Control Connection
ARCAM Radia control input
Trigger Connections
12V trigger input and output
Remote Control
Compact infrared remote included
Maximum Power Consumption
350 watts
Standby Power Consumption
Less than 0.5 watt
Network Standby Consumption
Less than 2 watts
Maximum Operating Temperature
95°F / 35°C
Dimensions
16.97 × 13.54 × 3.27 in
431 × 344 × 83mm
W × D × H, including terminals and feet
Net Weight
17.6 lbs. / 8 kg
Packed Weight
24.3 lbs. / 11 kg
Chassis Materials
Aluminum front, top, side and rear panels with solid aluminum control dials
Packaging
Plastic-free packaging
