Product Type
Stereo integrated amplifier with Bluetooth, DAC, HDMI eARC, USB-C and MM phono stage
Amplifier Class
Fifth-generation Class G
Continuous Power into 8 Ohms
100 watts per channel, 20Hz–20kHz, both channels driven, 0.5% THD
Continuous Power into 4 Ohms
165 watts per channel at 1kHz, both channels driven, 0.5% THD
Harmonic Distortion
0.002% at 80% power, 8 ohms, 1kHz
Analog Line Inputs
3 × stereo RCA pairs
Analog Input Frequency Response
20Hz–20kHz, ±0.2dB
Analog Signal-to-Noise Ratio
106dB, A-weighted, referenced to 50 watts and 1V input
Phono Input
1 × stereo RCA moving-magnet input with ground terminal
Phono Input Impedance
47 kilohms + 100pF
Phono Frequency Response
20Hz–20kHz, ±1dB referenced to the RIAA curve
Digital-to-Analog Converter
ESS ES9018
USB Digital Input
1 × USB-C
USB-C Sample Rates
44.1, 48, 88.2, 96, 176.4, 192, 352.8 and 384kHz
Other Digital Sample Rates
44.1, 48, 88.2, 96, 176.4 and 192kHz
Supported Digital Bit Depths
16-bit, 24-bit and 32-bit
Digital Frequency Response
20Hz–20kHz, ±0.2dB with Filter 1
Digital Signal-to-Noise Ratio
109dB, A-weighted, referenced to 50 watts and 0dBFS
Coaxial Digital Inputs
2 × RCA S/PDIF
Optical Digital Input
1 × Toslink
HDMI Input
1 × HDMI eARC/ARC
Bluetooth Version
Bluetooth 5.4
Bluetooth Profiles
A2DP sink/source, AVRCP and Bluetooth Low Energy
Wireless Audio Support
Snapdragon Sound, AAC, LE Audio and Auracast
Auracast
Supported with compatible Bluetooth LE Audio headphones and speakers
Bluetooth Frequency
2,400MHz–2,483.5MHz
Bluetooth Transmitter Power
Less than 20dBm
Headphone Output
Front-panel wired headphone output
Headphone Output Level
2.5V RMS into 32 ohms; 5V RMS into 300 ohms
Headphone Load Range
16 ohms–2 kilohms
Preamplifier Output
1 × variable stereo RCA output
Speaker Outputs
1 × stereo pair of binding posts
Recommended Speaker Impedance
4–16 ohms
Control Connection
ARCAM Radia control input
Trigger Connections
12V trigger input and output
Service Connection
USB service port
Remote Control
Compact infrared remote included
Mains Voltage
100V, 110–120V or 220–240V; 50–60Hz
Maximum Power Consumption
500 watts
Standby Power Consumption
Less than 0.5 watt
Dimensions
16.97 × 13.54 × 3.27 in
431 × 344 × 83mm
W × D × H, including speaker terminals and feet
Net Weight
19.8 lbs. / 9 kg
Packed Weight
26.5 lbs. / 12 kg
Chassis Materials
Aluminum front, top, side and rear panels with solid aluminum control dials
Packaging
Plastic-free packaging
