Anthem MRX 1140 8K 15.2 Pre-Amplifier / 11 Amplifier Channel A/V Receiver with Dolby Atmos, DTS:X and IMAX Enhanced

15.2-Channel Processing • 11 Amplified Channels • 140 Watts per Channel • ARC Genesis Room Correction • Seven 8K HDMI Inputs • Dolby Atmos • DTS:X • IMAX Enhanced • 32-Bit/768kHz DACs

Reference-Level Anthem Home Theater Processing with Eleven Channels of Amplification

The Anthem MRX 1140 8K 15.2 Pre-Amplifier / 11 Amplifier Channel A/V Receiver is designed as the control and power center of an advanced home theater system. It combines processing for up to 15.2 channels with eleven internal amplifier channels, allowing a complete 7.1.4 Dolby Atmos system to be powered directly while retaining additional preamplifier channels for system expansion with external amplification.

Seven HDMI 2.1 inputs support 8K/60Hz and 4K/120Hz video, while Dolby Atmos, DTS:X and IMAX Enhanced decoding deliver precise three-dimensional audio placement. Anthem’s ARC Genesis room-correction platform, high-resolution 32-bit/768kHz DACs, flexible amplifier assignment and extensive control integration make the MRX 1140 8K equally suited to dedicated theaters, media rooms and high-performance music systems.

Highlights & Benefits

  • 15.2-Channel Processing — Supports expansive immersive-audio systems with up to fifteen main-zone channels and two independent subwoofer outputs.
  • Eleven Internal Amplifier Channels — Powers a complete 7.1.4 loudspeaker layout without requiring an external power amplifier.
  • ARC Genesis Room Correction — Measures the speakers and room, then applies advanced correction to improve tonal balance, bass integration and imaging.
  • Seven 8K HDMI Inputs — Supports 8K/60Hz, 4K/120Hz, Variable Refresh Rate and Auto Low Latency Mode for movies, streaming and gaming.
  • Flexible Amplifier Matrixing — Reassign internal channels for front-wide, height, Zone 2 or bi-amplified speaker configurations as the system evolves.

Technology & Design

ARC Genesis Room Correction — Anthem Room Correction uses a calibrated microphone and advanced software to measure the acoustic behavior of the room and connected loudspeakers. ARC Genesis can create and store up to four speaker profiles with independent speaker layouts, bass management, levels and correction settings.

15.2-Channel Object-Based Audio Processing — The Anthem MRX 1140 8K supports Dolby Atmos, DTS:X and IMAX Enhanced soundtracks. Its processing platform can accommodate conventional surround, front-wide and up to six height-channel speakers when supplemented with appropriate external amplification.

32-Bit/768kHz Digital Conversion — High-resolution DACs process incoming digital audio with precise timing and low noise. The circuit platform is engineered to preserve detail, dynamic contrast and spatial information across movie soundtracks, multichannel music and two-channel playback.

HDMI 2.1 Video Platform — Seven dedicated HDMI inputs handle modern video formats including 8K/60Hz and 4K/120Hz pass-through. Features such as VRR and ALLM support responsive gaming, while eARC allows compatible televisions to return high-resolution audio through the primary HDMI output.

FAQ — Anthem MRX 1140 8K

Can the Anthem MRX 1140 8K power a 7.1.4 Dolby Atmos system?

Yes. The Anthem MRX 1140 8K includes eleven internal amplifier channels and is configured by default to power a 7.1.4 main-zone speaker system.

Why does the receiver process 15.2 channels but amplify only eleven?

The additional preamplifier channels allow larger configurations using external power amplifiers. This provides flexibility for systems with front-wide speakers, six height channels or upgraded amplification for the main speakers.

Does the MRX 1140 8K include Anthem Room Correction?

Yes. ARC Genesis software and a calibrated measurement microphone are included. ARC can optimize speaker response, crossover integration, bass performance and listening-position consistency.

Does the MRX 1140 8K support 4K/120Hz gaming?

Yes. Its HDMI 2.1 platform supports compatible 4K/120Hz and 8K/60Hz video sources, along with gaming features including Variable Refresh Rate and Auto Low Latency Mode.

Why Buy From Us

  • Authorized Anthem Dealer
  • 5% Reward Points on Every Purchase
  • Price Match Guarantee
  • Expert Home Theater Design, ARC Calibration and Professional Installation Support

Anthem MRX 1140 8K Specifications

Product Type
15.2-channel A/V receiver with eleven internal amplifier channels
Preamplifier Channels
15.2
Internal Amplifier Channels
11
Default Amplified Configuration
7.1.4 channels
Main Amplifier Power
140 watts per channel into 8 ohms
20Hz–20kHz, 1% THD, two channels driven, channels 1–5
Main Amplifier Power at 6 Ohms
170 watts per channel
20Hz–20kHz, 1% THD, two channels driven, channels 1–5
Additional Amplifier Power
60 watts per channel into 8 ohms
20Hz–20kHz, 1% THD, two channels driven, channels 6–11
Additional Power at 6 Ohms
75 watts per channel
20Hz–20kHz, 1% THD, two channels driven, channels 6–11
Room Correction
ARC Genesis with calibrated microphone
Speaker Profiles
Up to four independently configurable profiles
Surround Formats
Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS:X, DTS-HD Master Audio, DTS-HD High Resolution and DTS
IMAX Enhanced
Supported
DAC Resolution
32-bit / 768kHz
HDMI Inputs
7 × HDMI 2.1
HDMI Outputs
3 total, including one eARC-capable output
Maximum Video Resolution
8K/60Hz and 4K/120Hz pass-through
HDCP
HDCP 2.3
Gaming Features
Variable Refresh Rate and Auto Low Latency Mode
HDR Support
HDR10, HDR10+, Dolby Vision and Hybrid Log-Gamma
Analog Audio Inputs
5 × stereo RCA pairs
Coaxial Digital Inputs
2 × RCA coaxial
Optical Digital Inputs
3 × Toslink
Optical Digital Output
1 × fixed-level stereo downmix output
Preamplifier Outputs
15.2-channel unbalanced RCA
Subwoofer Outputs
2 independent RCA outputs
Zone 2
Independent source selection and volume control
Headphone Output
Front-panel 6.3mm headphone jack
Network Connection
Ethernet and Wi-Fi
Wireless Audio
Bluetooth, AirPlay 2 and Chromecast built-in
Streaming Support
Spotify Connect and compatible network-streaming services
Roon
Roon Ready
Web User Interface
Browser-based setup, control and configuration
Control Connections
Ethernet, Wi-Fi, RS-232, IR input and 12V trigger outputs
Amplifier Assignment
Assignable front, surround, back and height amplifier channels
Bi-Amp Capability
Supported using assignable amplifier channels
Front-Panel Display
Dimmable information display
Dimensions
17 × 6 × 14.5 in.
432 × 152 × 371 mm
W × H × D
Weight
Approximately 33.4 lbs. / 15.1 kg
Finish
Black
Quantity
Each
Brand
Anthem

What's in the Box

  • 1 × Anthem MRX 1140 8K A/V Receiver
  • 1 × Anthem Remote Control
  • 2 × Remote-Control Batteries
  • 1 × ARC Genesis Calibrated Microphone
  • 1 × Microphone Stand
  • 1 × Microphone USB Cable
  • 2 × Wireless Antennas
  • 1 × Detachable AC Power Cord
  • 1 × Operating Documentation

Loudspeakers, subwoofers, external power amplifiers, HDMI cables, speaker cables, Ethernet cable, source components and professional installation services are sold separately.
