Onkyo TX-SR494 7.2 Channel A/V Receiver

Onkyo TX-SR494 7.2 Channel A/V Receiver - Onkyo

From easy Bluetooth® wireless streaming to the heart-pounding thrills of Dolby Atmos® and DTS: X® soundtracks, the TX-SR494 A/V receiver delivers outstanding sound. Seven channels of high-current power give you the freedom to choose a speaker layout that suits you. As the heart of your home theater, the TX-SR494 A/V receiver is outfitted with HDMI® terminals supporting HDR and 4K/60p video, while the GUI with OSD over HDMI, Zone B pre-/line-out, and Vocal Enhancer function make this receiver easy to integrate.

Dolby Atmos Height Virtualizer or DTS Virtual: X® place sound overhead or behind if you don’t want height or surround speakers and both Dolby Surround® and DTS Neural: X® are on-board. Rear surrounds, bi-amped front speakers or Powered Zone B audio are also an option. AccuEQ with subwoofer EQ and AccuReflexTM for 5.2.2-ch Dolby Atmos-enabled systems clarify sound in any space.

• Dolby Atmos® and DTS:X® – setting sound free
• Dolby Atmos Height Virtualizer
• Ready for 4K HDR entertainment
• EASY BLUETOOTH VOLUME CONTROL

Dolby Atmos® and DTS:X® – setting sound free
Dolby Atmos® and DTS:X® formats allow engineers to map sound anywhere in 3D space, effects moving from speaker to speaker all around the room and wrapping your audience in the latest films and games. You can also enjoy your 3D speaker layout with classic titles. Dolby Surround® and DTS® Neural:X find overhead cues in legacy soundtracks and upmix for awesome spatial realism.

Dolby Atmos Height Virtualizer
When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.

Ready for 4K HDR entertainment
Enjoy support for HDR (High Dynamic Range) video including HDR10, HLG, Dolby Vision®, and BT.2020. The 4:4:4 color space is also supported. Six HDMI inputs, ARC-ready MAIN OUT, and SUB OUT pass 4K/60p and HDR video from player to compatible TV and projector and all terminals are HDCP 2.2 compliant.

EASY BLUETOOTH VOLUME CONTROL
Outfitted with the latest Bluetooth technology, this receiver gives you the freedom to choose how loud you experience your music, movies, and games. Listen quietly through your Bluetooth headphones without sacrificing sound quality or waking your kids. Or, while the rest of the family enjoys the speakers at a moderate volume, accommodate one person who may need help hearing via Bluetooth headphones.

Features:

• Amplifier
• # Channels: 7.2
• Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC): 80 Watts, 0.08% THD
• Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC): 160 Watts, 10% THD
• H.C.P.S. (High Current Power Supply)
• Certified 4 Ohms Performance
• Discrete Output Stage Circuitry
• Bi-amp Capability For Front
• Processing
• Dolby Atmos: 5.2.2
• 32-Bit Digital Signal Processing Engine
• Dolby Atmos Height Virtualizer
• Dolby Surround® upmixing
• Dolby Decoder:
• Dolby Atmos, Dolby True HD
• DTS:X: 5.2.2
• DTS Virtual:X
• DTS Neural:X upmixing
• DTS Decoder: DTS:X, DTS-HD Master Audio
• CinemaFILTER
• AccuEQ Room Calibration: w/ AccuReflex
• Direct
• Advanced Music Optimizer
• 384K/32 Bit DACs
• Connectivity
• Analog Audio IN: 3
• Digital Audio IN (OPT/COAX): 1/1
• USB Input
• HDMI I/O: 4/1
• HDMI 4K/60 Hz- Capable HDMI Terminals
• HDCP 2.3 Copy-Protection Compatibility
• HDMI Support for High Dynamic Range
• HDMI Support for 3D, Audio Return Channel and CEC
• BT.2020 Support
• HDMI Support for Deep Color, x.v.Color, LipSync
• HDMI Support for DVD-Audio, SACD, Multichannel PCM
• 1080p to 4K Upscaling
• 4K Passthrough
• Analog Pre-Outs: Dual Subwoofer
• Zone B Line Out
• Bluetooth
• Miscellaneous
• Auto Speaker Calibration W/Mic.: AccuEQ
• OSD Out

Specs

• Amplifier
• All channels: 80 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) 160 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
• THD+N (Total Harmonic Distortion + Noise): 0.08% (20 Hz–20 kHz, 8 Ohms, 1 Channel Driven, 80 W)
• Input sensitivity and impedance: 200 mV / 47k Ohms (Line)
• Frequency response: 10 Hz–100 kHz /+ 1 dB, -3 dB (Direct Mode)
• Tone control: ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
• Signal-to-noise ratio: 109 dB (Line, IHF-A)
• Speaker impedance: 4 ohms–16 ohms
• Video
• Video: 1.0 Vp–p ±5% / 75 Ohms (Composite)
• Tuner
• FM: 87.5 MHz–107.9 MHz
• AM: 530 kHz–1,710 kHz
• FM/AM preset memory: 40 stations
• General
• Power supply: AC 120 V~, 60 Hz
• Power consumption: 490 W
• Power consumption (standby): 0.1 W
• Dimensions (W x H x D): 17 1/8" x 6 5/8" x 12 15/16" (435 x 160 x 328 mm)
• Weight: 18.1 lbs (8.2 kg)
• Carton
• Dimensions (W x H x D): 20 11/16" x 9 7/16" x 15 15/16" (525 x 240 x 405 mm)
• Weight: 23.1 lbs. (10.5 kg)
