MOON 860A v2 Stereo Power Amplifier

$20,000.00
$20,000.00

1-800-513-8555 for details.

Call For Details

FREE 60 Day Returns

MOON 860A v2 Stereo Power Amplifier

MOON 860A v2 Stereo Power Amplifier

$20,000.00

MOON 860A v2 Stereo Power Amplifier

$20,000.00

MOON 860A v2 Stereo Power Amplifier - MOON

860A v2 Power Amplifier
Transparency and soundstage are exceptional, despite this amplifier’s high power rating. Ultimately, the MOON 860A v2 Power Amplifier will mate seamlessly with any loudspeaker allowing it to reach its full sonic potential, regardless of its load.

Exceptional transparency

The MOON 860A v2 Power Amplifier is a balanced differential dual-mono Power Amplifier that provides both exceptional transparency and a remarkable musical soundstage.

A true evolution

A true evolution on earlier designs, and incorporates trickle-down technologies from the massive 888 Power Amplifier.

225W per channel

450W at 4 Ω and 750W in monaural mode

Design features:

  • Monaural operation via rear-panel switch.
  • DC-coupled design with DC-servo control for greatest transparency.
  • Switchable AC-coupling for best match with a variety of preamplifiers.
  • Output stable into any load impedance.
  • Class A power output up to 5 watts.
  • Very high damping factor for superior musical dynamics, speaker control and refined harmonic accuracy and timbre.

Specifications:

  • Output Power at 8Ω: 225 W per channel
  • Output Power at 4Ω: 450 W per channel
  • Output Power - Monaural mode at 8Ω: 750 W
  • Input Sensitivity: 1.2V
  • Input Impedance: 47,500Ω
  • Gain: 31dB
  • Signal-to-noise Ratio: 110dB @ full power
  • Frequency response (full range): 10Hz - 55kHz +0/-3.0dB
  • Crosstalk @ 1kHz: -110dB
  • THD (20Hz - 20kHz @ 1 W): 0.005%
  • THD (20Hz - 20kHz @ 200 W): 0.03%
  • Intermodulation distortion: 0.006%
  • Power Supply Capacitance: 240 000 uF
  • Shipping weight: 90 lb / 40 kg
  • Dimensions (width x height x depth): 18.75 x 7.5 x 17.5 in

In The Box:

  • The following accessories should be included inside the box with your power amplifier:
  • AC power cable
  • Owner’s manual
  • Warranty and product registration information (USA and Canada only)
